INCH-POUND
A-A-52472A
March 2, 2011
SUPERSEDING
A-A-52472
August 31, 1993
COMMERCIAL ITEM DESCRIPTION
FILTER, FLUID, PRESSURE, AUTOMOTIVE
FUEL (10 GPH FILTRATION)
The General Services Administration has authorized the use of this commercial item
description (CID) as a replacement for MS51085C, which is cancelled. This CID also
replaces the portions of cancelled MIL-F-45356B, which apply to MS51085C.
1. SCOPE. This CID covers requirements for a filter assembly with a fine filtration element for
use in the fuel systems of internal combustion gasoline engines and personnel heaters.
2. CLASSIFICATION. Filter assemblies shall be furnished in the following types (see 7.2).
Type I
-
Filter assembly with 15 pounds per square inch (psi) pressure requirements,
without lockwire.
Type II -
Filter assembly with 300 psi air pressure requirements, with lockwire.
3. SALIENT CHARACTERISTICS
3.1 Materials. Unless otherwise specified herein, the materials used shall be in accordance with
the manufacturer s materials specifications for pressure fluid filter as required to meet the
performance requirements of this CID. The use of recovered materials made to conform to
regulatory requirements is acceptable provided all requirements of this CID are met (see 4).
3.1.1 Cover (head). Type II filter covers shall be made of metal. If made of steel, cover
material shall be zinc coated, and the finished cover shall be treated with a corrosion resistant
inhibitor as per ASTM D6386.
Beneficial comments, recommendations, additions, deletions, clarifications, etc. and any data that
may improve this document should be sent to DAMI_STANDARDIZATION@conus.army.mil or
U.S. Army RDECOM, Tank Automotive Research, Development and Engineering Center,
ATTN: RDTA-EN/STND/TRANS MS #268, 6501 E. 11 Mile Road, Warren, MI 48397-5000.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 2910
