A-A-52468
Superseded
Diameter
Diameter
Width
CID PIN 2/
MS Part No.
`A'
`B'
`C'
3.270 + .024
3.030 + .010
.125 + .008
A 52468-1
MS51091-1
(83.0 + .5)
(80.0 + .2)
(3.2 + .2)
1.121 + .010
.858 + .005
.161 + .010
A 52468-2
MS51091-2
(28.5 + .2)
(22.0 + .1)
(4.0 + .2)
1.000 + .010
.485 + .005
.125 + .010
A 52468-3
MS51091-3
(25.5 + .2)
(12.3 + .1)
(3.2 + .2)
2.005 + .010
1.562 + .010
.062 + .010
A 52468-4
MS51091-4
(51.0 + .2)
(39.7 + .2)
(1.6 + .2)
1.780 + .010
.060 + .010
2.110 + .010
A 52468-5
MS51091-5
(53.5 + .2)
(45.2 + .2)
(1.5 + .2)
NOTES:
1.
Dimensions in inches (millimeters).
2/
PIN = Part or identification number.
FIGURE 1. Gasket sizes.
d. Identification and marking. Identification and marking of the gaskets shall be as specified in the
packaging requirements and shall include, as a minimum, the CID PIN, manufacturer's CAGE code, and
material cure date (quarter and year).
2
