MIL-PRF-14442E(AT)
specified in 4.9.2. The jig shall be designed so that removal of the tank test structure may be
accomplished with a minimum effort.
4.3 First article inspection. When a first article sample is required (see 3.1), samples shall
be inspected as specified in table I. First article samples shall be selected as follows:
Three full size tanks complete with necessary fittings.
Three 12 by 12 in. specimens of composite tank construction.
One specimen of inner layer ply, without barrier, approximately 900 square inches (in2)
in area, including seam.
One specimen of 6 by 6 in. inner layer ply, without barrier.
Three permeability specimens in accordance with 4.8.3.2.
TABLE I. Classification of inspections.
Title
Requirement Verification
Title
Requirement
Verification
3.3
4.6
Fluid resistance of
3.5.5
4.8.2
Interface and
exterior surfaces
interoperability
Installation
3.3.1
4.6.1
Permeability
3.5.6
4.8.3
Stand
3.3.2
4.6.2
Tensile strength
3.5.7
4.8.4
Fuel contamination
3.3.3
4.6.3
Seam adhesion
3.5.8
4.8.5,
4.8.5.1
3.4
4.7
Wet seam adhesion
3.5.8.1
4.8.5.2
Environmental
Humidity at elevated
3.4.1
4.7.1
Puncture resistance
3.5.9
4.8.6
temperature
Humidity at room
3.4.2
4.7.2
Identification
3.5.10
4.8
temperature
marking
Low temperature leakage
3.4.3
4.7.3
Filler cap
3.5.10.1
4.8
3.5
4.8
Hand-hole cover
3.5.10.2
4.8
Support and ownership
Hazardous materials
3.5.1
4.8
Torque values
3.5.10.3
4.8
Protective treatments
3.5.2
4.8
3.6
4.9
Operating
Fittings
3.5.2.1
4.8
Capacity
3.6.1
4.9
Openings
3.5.2.2
4.8
Leakage
3.6.2
4.9.1
Access opening
3.5.3
4.8
Slosh
3.6.3
4.9.2
Handling
3.5.4
4.8.1
4.4 Conformance inspection. Conformance inspection shall include the applicable tests of
table I as specified in the contract (see 6.2).
4.5 Verification methods. The types of verification methods included in this section are
examination of contractor records, visual inspection, measurement, sample tests, full-scale
demonstration tests, simulation, modeling, engineering evaluation, component properties analysis,
and similarity to previously-approved or previously-qualified designs.
6
